T-1000S LED Controller Guide The T-1000S is a basic LED controller designed for small-scale LED pixel installations. With SPI protocol support and SD card storage, this controller offers simple yet effective control for home and small business LED projects. Technical Specifications Specification Details Output Ports 1 Max Pixel Control 2048 pixels Compatible LEDs WS2811, WS2812B, SK6812, APA102, TM1804, UCS1903, etc. Input Voltage DC 5V-24V Output Protocol SPI Dimensions 88×48×25mm Memory On-board storage for multiple programs SD Card Support Micro SD up to 32GB Clock Function No ⚠️ Important Compatibility Notes: ...

K-1000C LED Controller Guide The K-1000C is a professional-grade LED controller designed for medium-scale LED pixel installations. With support for both DMX and SPI protocols, this controller offers versatile control options for a wide range of addressable LED applications. Technical Specifications Specification Details Output Ports 1 Max Pixel Control 2048 pixels Compatible LEDs WS2811, WS2812B, SK6812, APA102, TM1804, UCS1903, etc. Input Voltage DC 5V-24V Output Protocol DMX/SPI Dimensions 88×48×25mm Memory On-board storage for multiple programs SD Card Support Micro SD up to 32GB Clock Function Built-in RTC with scheduling capabilities ⚠️ Important Compatibility Notes: ...

T-8000A LED Controller Guide The T-8000A is a professional-grade LED controller designed for large-scale LED pixel installations. With support for DMX and Art-Net protocols, 8 output ports, and advanced network control capabilities, this controller is ideal for professional shows and large installations. Technical Specifications Specification Details Output Ports 8 Max Pixel Control 8192 pixels (1024 per port) Compatible LEDs WS2811, WS2812B, SK6812, APA102, TM1804, UCS1903, etc. Input Voltage DC 5V-24V Output Protocol DMX/Art-Net Network Interface Ethernet (10/100Mbps) Dimensions 88×48×25mm Memory On-board storage for multiple programs SD Card Support Micro SD up to 32GB Clock Function Built-in RTC with scheduling capabilities ⚠️ Important Compatibility Notes: ...

K-8000C LED Controller Guide The K-8000C is an advanced professional-grade LED controller designed for large-scale LED pixel installations. With support for DMX, Art-Net, and sACN protocols, 8 output ports, and cloud control capabilities, this controller is ideal for professional venues and complex shows requiring advanced networking features. Technical Specifications Specification Details Output Ports 8 Max Pixel Control 8192 pixels (1024 per port) Compatible LEDs WS2811, WS2812B, SK6812, APA102, TM1804, UCS1903, etc. Input Voltage DC 5V-24V Output Protocol DMX/Art-Net/sACN Network Interface Ethernet (10/100Mbps) Cloud Control Yes Dimensions 88×48×25mm Memory On-board storage for multiple programs SD Card Support Micro SD up to 32GB Clock Function Built-in RTC with scheduling capabilities ⚠️ Important Compatibility Notes: ...

Synchronizing Multiple K-1000C Controllers for Large LED Displays Introduction While the K-1000C is a powerful single-port controller ideal for medium-scale LED pixel installations, sometimes your project will exceed its 2048-pixel limit or require distributed control across a large area. In these cases, you can synchronize multiple K-1000C controllers to work together, creating seamless effects across your entire LED display. Why Synchronize Multiple K-1000C Controllers? Expand Pixel Count: Control more than 2048 pixels by splitting your project across several controllers. Distributed Installations: Place controllers closer to different LED sections to reduce wiring complexity and signal loss. Redundancy: If one controller fails, others can continue operating. Methods for Synchronizing K-1000C Controllers 1. SD Card Program Synchronization The most common method is to use identical SD cards in each controller, each loaded with the same effect files generated by LED Edit. ...
