T-1000S LED Controller Guide
The T-1000S is a basic LED controller designed for small-scale LED pixel installations. With SPI protocol support and SD card storage, this controller offers simple yet effective control for home and small business LED projects.
Technical Specifications
| Specification | Details |
|---|---|
| Output Ports | 1 |
| Max Pixel Control | 2048 pixels |
| Compatible LEDs | WS2811, WS2812B, SK6812, APA102, TM1804, UCS1903, etc. |
| Input Voltage | DC 5V-24V |
| Output Protocol | SPI |
| Dimensions | 88×48×25mm |
| Memory | On-board storage for multiple programs |
| SD Card Support | Micro SD up to 32GB |
| Clock Function | No |
⚠️ Important Compatibility Notes:
- 💾 Make sure your SD card is compatible with the controller - some models only accept older SD cards
- ⚠️ Old and cheap T1000 models work only with LEDEdit 2014!
- ❓ Ask your seller about software support
- 🔍 Check maximum LED count in software - some chips can have different maximum values!
Key Features
- Simple Control: Easy-to-use SPI protocol
- Basic Effects: Support for standard animations and patterns
- SD Card Support: Store and play multiple effect programs
- Compact Design: Small form factor for easy installation
- Cost-Effective: Budget-friendly option for small projects
- Reliable Operation: Stable performance for basic applications
Connection Guide
The T-1000S features straightforward connections:
- Power Input: Connect DC 5V-24V power supply (match to your LED voltage)
- LED Output: 3-pin connector (GND, DATA, +V)
- SD Card Slot: For storing and playing programs
- Status LED: Power and data activity indicator
Wiring Recommendations
- Use standard data cables for signal transmission
- Maximum recommended data line length is up to 5 meters
- For runs over 3 meters, consider using signal amplifiers
- Use proper power injection for installations over 3 meters
- Match power supply voltage to your LED strip requirements
Setup Guide
Basic Setup
- Insert SD card with your program
- Connect power supply
- Connect LED strip
- Power on the controller
SD Card Management
The T-1000S supports SD card storage for multiple programs:
- Format a micro SD card to FAT32 (32GB or smaller)
- Save your programs to the SD card
- Insert the SD card into the controller
- Use the controller menu to select programs
Troubleshooting Common Issues
No LEDs Lighting Up
- Verify power connections to both controller and LED strips
- Check that LED strip voltage matches controller power supply
- Ensure correct data pin connection
- Test with a simple one-color program
Controller Not Working
- Check SD card format and compatibility
- Verify program compatibility
- Check power supply connections
- Ensure proper grounding
Flickering or Unstable Operation
- Check for proper grounding between power supply and LED strips
- Verify data signal integrity with shorter cables
- Ensure power supply has sufficient capacity
- Check for interference from nearby electrical equipment
Comparison with Other Controllers
| Feature | T-1000S | K-1000C | T-8000A | K-8000C |
|---|---|---|---|---|
| Output Ports | 1 | 1 | 8 | 8 |
| Max Pixels | 2048 | 2048 | 8192 | 8192 |
| Protocol | SPI | DMX/SPI | DMX/Art-Net | DMX/Art-Net/sACN |
| SD Card | Yes | Yes | Yes | Yes |
| Network Control | No | Yes | Yes | Yes |
| Price Range | Low | Mid | High | High |
Common Applications
The T-1000S is ideal for:
- Home Lighting: Basic LED strip installations
- Small Displays: Simple signage and decorations
- Holiday Lighting: Residential holiday displays
- Basic Effects: Simple animations and patterns
Resources and Support
- LED Edit Effects - Download compatible effects
Conclusion
The T-1000S offers basic LED control capabilities with SPI protocol support, making it suitable for small-scale installations and home projects. With its 2048 pixel capacity and SD card storage, it provides a cost-effective solution for basic LED control needs.
For more advanced features like DMX support or network control, consider upgrading to the K-1000C or T-8000A controllers.
